1.     Tape:

Scotch® filament tape.

2.     Tape Width: 胶带宽度9-36MM

3/8 inch [9mm], to 1-1/2 inch [36mm].

3.     Tape Roll Diameter: 胶带卷外径：115MM, 胶带卷内径：76.2MM
Up to 15 inches [115mm] maximum on a 3 inch [76.2mm] diameter core.

4.     Applied Tape Length: 两边带长：55+-3.2MM
4-1/2 inches [115mm] (nominal). Tape legs are 2-1/4 inches ±1/8 inch [55mm ±3.2mm].

5.     Box Size Capacity (Applying two "L" Clips):

Height – Width –

Depth –

2-1/4 inches [60mm] minimum to unlimited maximum. 13 inches [330mm] minimum to unlimited maximum

(Single clip application requires 3-1/4 inch [85mm] minimum box width.) 2-1/4 inches [60mm] minimum to unlimited maximum

Note – Operator capability will determine maximum height, width and depth. For other size requirements, please contact your 3M sales representative.

6.     Cycle Time: 1.2 seconds  打包时间 1.2秒

7.     Compressed Air Requirements: 65 PSIG [4.2 bar gauge pressure] 压缩空气65PSIG

4.3 SCFM [120 liter/minute @ 21C, 1.0 bar] at 50 cycles/minute

8.     Operating Conditions:

Use in dry, relatively clean environments at 40°F to 120°F [5°C to 49°C] with clean, dry boxes.

Note – Machine should not be washed down or subjected to conditions causing moisture condensation on components.

9. Weight:
275 pounds [125 kg] unpackaged  净重 125KG

350 pounds [160 kg] packaged  毛重160KG
